Year of manufacture 2000
Working dimension X 4743
Working dimension Y 1560
Working dimension Z 250
Number of routing spindles 1
Main motor power kW 12
Rotation speed max rpm 24000
Torque support 1
Rotational axes C-axis
Tool clamping system HSK-F63
Tool changing positions 18
Number of exchangeable units 1
Borer vertical 22
Horizontal drills in X 4
Horizontal drills in Y 2
Saw aggregate Unit, changeable
Cantilever machine 1
Machine table Pod and rail table
Number of table bars 8
Positioning aid 1
Vacuum pump 1
Capacity vacuum pump m³/h 100
Safety device Shut-off mat
Chip conveyor 1
CE-mark 1
Availability from about August 2016
Operating status still in production use
Condition suitable for use
